Features

• Can be used in areas with restricted operator space
• Available with in-line handle and top or bottom hose configuration äóñ optimised ergonomic performance for improved productivity
• Average cycle time of less than 2 seconds äóñ increased productivity äóñ up to 1500 fasteners per hour
• High capacity, magazine fed fasteners äóñ reduced component handling and subsequent spillage
• Lightweight construction and zero action recoil äóñ reduced operator fatigue
• Long life, self priming intensifier äóñ consistent actuation and hence joint formation
• Long reach barrel äóñ can be used in many difficult access applications
• Low maintenance hand tool äóñ productive time is maximised äóñ no requirement for specialist maintenance training
• Robust & durable construction äóñ suitable for most industrial environments

Specification

• Air Supply Pressure Minimum/Maximum bar: 5~7
• Free Air Volume Required bar(liters): 5.1(2.6)
• Stroke: 30 mm
• Pull Force: 874(389) lbf(kgf)
• Cycle Time Approximately: 1second
• Noise Level Less than: 70 db(a)
• Net Weight: 2.38(1.08) Ibs(kgs)
• Vibration Less than m/s²: 2.7
